Description

Lindy 36947 USB4 Type C

The Anthra Line USB 4 Type C to C cable from Lindy's Cable Lines concept is the professional choice for high performance connections in commercial AV and IT installations.

Anthra Line USB 4 cables are premium connections that feature triple shielded construction with silver plated copper conductors for performance and corrosion resistance. High quality gold plated contacts and nickel plated connectors maintain optimal signal integrity and maximum reliability.

USB bandwidths up to 40Gbps are supported for rapid transfer of large data volumes. These cables are E-marked to provide 100W (5A) of power to devices using the most efficient power delivery profiles.

USB Type C features a reversible connector, so no matter which orientation the cable is inserted, a connection will always be found. This connector allows a fully bi-directional cable with automatic host and device negotiation.

PRODUCT DETAILS

• Professional choice USB 4 Gen 3x2 Type C to C cable for commercial and high performance AV and IT installations
• Supports data transfer speeds up to 40Gbps (backwards compatible to USB 3.2 , USB 2.0 and Thunderbolt 3)
• Supports DisplayPort 2.0 Alternate Mode and USB Power Delivery 3.0 up to 100 Watt (20V 5A)
• Triple shielded coaxial cable, gold plated contacts and nickel plated connectors

TECHNICAL INFORMATION:

Connectors

Connector A: USB 4 Type C Male
Connector B: USB 4 Type C Male
Housing Material: TPE
Connector Plating: Nickel
Pin Construction: Copper
Pin Plating: Gold
Dimensions (approx.) WxDxH: 30x12.4x6.5mm (1.18x0.49x0.26in)

Cable Construction

Length: 0.8m (2.62ft)
Standard: USB 4 Gen 3x2
Colour: Black
Type: Round
Jacket Diameter: 4.8mm (0.19in)
Jacket Material: TPE
Conductor Material: Silver plated copper
Conductor Gauge Power: 23AWG
Conductor Gauge Data: 30AWG/33AWG/34AWG
Shielding: Tinned Copper Braid 85%

Specifications

Supported Bandwidth: 40Gbps
Maximum Resolution: 8K@60Hz
Nominal Attenuation: 0.5Mhz-15Ghz ≤ 11dB
Minimum Band Radius: 28.8mm (1.13in)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40 °C - 80°C (-40°F - 176°F)
Certificated: RoHS, REACH, California Proposition, UL

Product is new, originally packed.

Functionality

The USB connector allows you to connect peripheral devices: printer, scanner, hard drive, USB flash drive, mouse, keyboard, camera, smartphone and others to a computer, laptop, tablet. Before purchasing a cable, check the type of USB input and output in the devices using the manual or information provided by the manufacturer's service.
In case of problems, it is possible to send a photo of the device sockets to the RMS.pl store service, which helps to identify the type of connector.

The service of the RMS.pl store is not able to provide information about the type of USB connector based on the manufacturer or model of the device.

Specifications

Length:	0.8m
Quality: Why copper purity is so important? The signal which is running through the guide should encounter on its way as little obstructions as possible. In case of low purity copper the amount of impurities which must be bypass is large. Then we can say that the signal has to go through a real slalom. In the purified copper, electrons run straight to the goal, so the sound is not distorted. Moreover, there is another argument. Copper impurities include oxygen atoms. They cause oxidation. Produced copper oxide which is much weaker conductor than the proper copper. In this way the conductivity deteriorates which obviously affects the sound. Source: information service RMS.pl	Silver plated Oxygen Free Copper
Shielding: Shielding is something like a barrier to electromagnetic interference. If the guide has more layers of shielding or the shielding is thicker, it's better. Source: RMS.pl	Triple Yes
Connectors:	USB C
Shape:	Round
Diameter (cable thickness):	4.8mm
Insulation:	TPE
Type:	Cable
USB: USB 1.1 devices complying with the conditions of this specification can be operated at a rate (Full Speed​​) 12 Mbit / s (1.5 MB / s) and (Low Speed) 1.5 Mbit / s (0.1875 MB / s). Date of announcing the specification: 08/23/1998. USB 2.0 (Hi-Speed) devices in accordance with the terms of the new specification can operate at a maximum speed of 480 Mbit / s (60 MB / s). The actual data transfer rate depends on the design of the device. Devices with USB 2.0 standard are fully compatible with older devices. Date of announcing the specification: 27.04.2000. USB 3.0 (SuperSpeed​​) devices in accordance with the terms of the new specification can be operated at a speed of 4.8 Gb / s (600 MB / s). The new standard in addition to the standard cables (for compatibility with USB 2.0 and 1.1) for fast transfer uses two additional shielded wire pairs in the duplex. The first presentation of this technology took place at CES 2008 Date announced specifications: 17.11.2008. Source: information service RMS.PL	USB 3.0 USB 3.1 USB 3.2 Gen1 USB 3.1 Gen 1 USB 3.2 Gen 2x2 USB4
Capacity: Channel capacity is the tight upper bound on the rate at which information can be reliably transmitted over a communications channel. Mostly given in bits per second. Source: RMS.pl information service	up to 48 GB/s
Spiral cable:	NO
Type:	USB C-C
Warranty:	24 months
GPSR - informacje:	Brand Comapny name: LINDY International Limited Address line Sadler Forster Way TS17 9JY Thornaby, United Kingdom of Great Britain and Northern Ireland e-mail: talktous@lindy.com Podmiot odpowiedzialny Comapny name: RAFKO Rafał Koc Address line Hetmańska 33B 15-727 Białystok, Polska Phone: 857479757
